Ara

Elipse Profiles - CR

Quality : S235JRH - S275J0H - S275J2H- S355J0H - S355J2H - S355K2H - S275NH - S275NLH - S275MH - S275MLH - S355NH - S355NLH - S355MH - S355MLH - S420 - S420MLH

Standard : TS EN 10305-3 - TS EN 10305-5 - DIN 2394 - DIN2395

Outer Diameter : 22x14 - 60x30 mm

Wall Thickness : 0.7 - 6 mm

Price List : /price-list/yucel-tube

Profiles Of The Ellipse

What Are The Profiles Of The Ellipse?

First architectural and maritime programs developed specifically for the profiles of the Ellipse has expanded its fields of use later. Both soft and due to the aesthetic structure , Ellipse profiles has become available to be used in different areas. The Ellipse profileof the maintenance costs are also quite low. The profiles of the Ellipse standard round profiles unlike more advantage. First, the profile of the Ellipse is much more powerful than the format we call a round profile. In this way, you are less likely to bending or twisting. Storage space in the form of the profiles of the Ellipse gives you a big edge. In the user space of the Ellipse profiles is limited. Needs reasonably profile Ellipse elliptical pipe types and dimensions can vary.

Products Features

For years steel product that met all the expectations of its customers with a wide range of sheet metal with many different companies, Hakan structural steel profilessupply I will. Profiles, universal beams, universal columns and by being offers a wide range. The profiles of the Ellipse is subject to various options in terms of size.

We have taken the base principle of continuity in the quality of our service. Each one is trained and equipped for continuous self-improvement with our team for your project that are open to the ideal profile, we welcome your needs.

Areas Of Use

The profiles of the Ellipse are known for its versatile features. Take a look at areas of use; hotels, offices, shopping centres, accommodation facilities, such as homes and is with a lot of options. Ellipse profile , even though the scope of use is limited, especially in the construction sector, building construction are preferred in private. The profiles of the Ellipse;

  • Direct, in special areas, such as columns,
  • And the same chairs,the furniture in
  • Lighting poles, street signs in areas such as,
  • Luggage on the shelves and on the railing,
  • Door handle and the same accessories in the profiles of the Ellipse are often preferred.

Weight Ruler

The Weight Of The Ellipse Ruler Profiles

Kg/m

The thickness of the meat / T (mm)

External dimension / a X B (mm)



0,7

0,8

0,9

1

1,2

1,5

2

22 x 14

0,30

0,34

0,38

0,42

0,50

0,62



30 x 15

0,39

0,44

0,49

0,55

0,65

0,80



40 x 20

0,56

0,59

0,66

0,74

0,88

1,09

1,42

60 x 30









1,41

1,75

2,32
